12V BB-2590 Battery Eliminator 220 Watt (18.3 Amp)

Part Number: SN-12V-03
$379.50
VOLUME-BASED PRICING
Quantity Price
50+
$371.91
100+
$364.32
250+
$356.73
In Production
  • 10 Unit(s) Expected 03/04/2024
6 - 8 Weeks
+ -
+ -

This 12V battery eliminator emulates a BA5590/BB-2590 battery in 12V mode at 18.3  Amps. Suitable for powering the AN/PRC-162. It can also power the AN/PRC-161, or AN/PRC-148 with the SN-200 adapter.

  • Input Voltage: 85 - 264VAC; 100 - 240VAC Nominal
  • Output Voltage: 12V @ 18.3 Amps
  • Ripple & Noise: < 120 uV
  • 12V on pin 4,5 Ground Pin 1,2
  • Size: 5" X 3" X 1.22"
  • Weight: 1.75 lbs.
  • Cable Length: 6 Ft.
  • 5 Year Warranty
  • Sand and Dust Proof
  • Operating Temperature: -40C to +60C
  • Humidity 95%
  • Operating Temp: 0-60C (Full load to 40C derate linearly to 50% load at 60C)
  • Built in Thermal Shutdown Protection

This 12V battery eliminator emulates a BA5590/BB-2590 battery in 12V mode at 18.3  Amps. Suitable for powering the AN/PRC-162. It can also power the AN/PRC-161, or AN/PRC-148 with the SN-200 adapter.

  • Input Voltage: 85 - 264VAC; 100 - 240VAC Nominal
  • Output Voltage: 12V @ 18.3 Amps
  • Ripple & Noise: < 120 uV
  • 12V on pin 4,5 Ground Pin 1,2
  • Size: 5" X 3" X 1.22"
  • Weight: 1.75 lbs.
  • Cable Length: 6 Ft.
  • 5 Year Warranty
  • Sand and Dust Proof
  • Operating Temperature: -40C to +60C
  • Humidity 95%
  • Operating Temp: 0-60C (Full load to 40C derate linearly to 50% load at 60C)
  • Built in Thermal Shutdown Protection
