High-Performance 24V BB-2590 Battery Eliminator for Military Radios
The 24V BB-2590 Battery Eliminator (Part Number: SN-24V-01, NSN: 6130-01-619-5244) is a reliable and efficient power supply designed to emulate the BB-2590, BA-5590, and BB-390 batteries in 24V mode. With an output of 24V at 6.3 Amps, this battery eliminator is capable of powering up to three AN/PRC-117G radios simultaneously, making it an essential tool for military communication setups. This durable power supply offers outstanding performance, designed for versatility and longevity, ensuring optimal operation even in the most challenging environments.
Key Features of the 24V BB-2590 Battery Eliminator
- Wide Compatibility: Compatible with multiple military radios, including; AN/PRC-117F, AN/PRC-117G, AN/PRC-150, AN/PRC-158, AN/PRC-160, AN/PRC-162 and AN/PRC-167.
- High Output Power: Delivers a steady 24V at 6.3 Amps, with a peak current of up to 7.5A.
- Rugged and Durable: Designed to be sand and dustproof, with an operating temperature range of -40°C to +60°C, making it suitable for harsh conditions.
- Thermal Protection: Features built-in thermal shutdown protection to prevent overheating during extended use.
- LED Indicator: Equipped with an LED indicator for easy monitoring of power status.
- Medical and EMC Safety Certified: Meets EN60601-1 Class I 3.1 Edition standards for medical approval and complies with IEC/EN 60601-1-2 4th edition EMC safety requirements.
- Universal Input Voltage: Accepts an input voltage range of 85 - 264VAC; 100 - 240VAC nominal, 50-60Hz.
- RoHS Compliant: Environmentally friendly, adhering to the RoHS compliance standards.
Reliable 24V Power Supply for Military and Industrial Applications
The 24V BB-2590 Battery Eliminator is designed for impeccable quality, offering a steady and reliable power output suitable for military, communication, and industrial applications. Its ability to power multiple devices simultaneously through a triple splitter (SN-306) or a 4-way splitter (SN-307) makes it versatile for field operations. The robust construction ensures long-lasting performance, while its medical and EMC certifications guarantee safety in critical environments. This battery eliminator offers seamless operation even under challenging conditions, making it a trusted solution for powering mission-critical equipment.
Detailed Specifications of the 24V BB-2590 Battery Eliminator
- Part Number: SN-24V-01
- NSN: 6130-01-619-5244
- Input Voltage: 85 - 264VAC; 100 - 240VAC Nominal, 50-60Hz
- Output Voltage: 24V @ 6.3 Amps, Peak Current 7.5A
- Ripple & Noise: Less than 240 uV
- Output Pin Configuration: 24V on pin 5, Ground Pin 1 (Pins 2 & 4 not connected)
- Dimensions: 5" x 3" x 1.22"
- Weight: 1.75 lbs
- Cable Length: 6 Ft
- Input Connector: NEMA 5-15P
- Operating Temperature: -40°C to +60°C
- Humidity: 95%
- Thermal Protection: Built-in thermal shutdown protection
- Medical Approval: EN60601-1 Class I 3.1 Edition
- EMC Safety: IEC/EN 60601-1-2 4th edition
- Efficiency: Level V
- Power Density: 5.4W/in3
- Lifetime Expectation: Greater than 5 years
- Warranty: 5-Year Warranty
- Certification: RoHS Compliant, CE marked to LVD and CE EMC
- Export Classification: Not restricted for export (EAR99)
- For use with: AN/PRC-117F, AN/PRC-117G, AN/PRC-150, AN/PRC-158, AN/PRC-162 and AN/PRC-167
The Industry-Standard Choice for Military Communication Power Solutions
The 24V BB-2590 Battery Eliminator stands out as an industry-standard solution for powering military radios and communication devices. Its rugged design, extensive compatibility, and reliable performance make it a popular choice among military professionals and industries requiring dependable power solutions. With its high efficiency, comprehensive safety certifications, and long operational life, this battery eliminator has earned its place as a trusted component in mission-critical operations worldwide.
